Triangle Tube High Efficiency Boilers
PRESTIGE SERIES HIGH EFFICIENCY CONDENSING BOILERS & COMBINATION UNITS
ACVMAX, User-friendly Control System
Choose from 6 standard heating applications to set up the boiler in 60 seconds or less
- Finned Tube
- Baseboard Cast Iron
- Baseboard Radiators
- High Mass
- Radiant Low Mass
- Radiant Fancoil
Integrated Cascade
- Joins up to 6 boilers
- Master boiler automatically recognizes linked boilers
- Meets simultaneous DHW & Space Heating calls
- Full Parallel Modulation
- Automatic Duty Cycling
Intelligent Troubleshooting
- Describes lockouts in plain English & suggests solutions
- Records sensor readings for 24 hours
- Stores last 8 errors.
Multiple Zone Control
- Accepts 2 space heating calls with independent outdoor reset curves
- Simultaneously heat dual temperature heating systems with built-in mixing valve control
- Manage up to 2 space heating zones and 1 DHW zone without an external zone control panel
Multiple Circulator Control
- Presets allow for quick configuration of 4 circulator outputs
- Circulator outputs fully configurable for custom applications
439 Stainless Steel Heat Exchanger
Our proven Firetube heat exchanger is not only corrosion resistant; it‘s also designed to maximize heat transfer with low thermal stress. That results in peace of mind with unparalleled reliability and longevity.
Low Maintenance Design
The condensate washes combustion residue away when streaming down the tubes for high efficiency and reduced maintenance.
“Tank-in-Tank” Technology (Combi)
The Prestige Excellence Combination Boiler incorporates our 14 gallon indirect fired water heater in the cabinet that is capable of producing 180 GPH of domestic hot water. Heating and Hot water perfectly integrated into one unit.
Installation Flexibility
Prestige works as the ideal solution for any installation by offering the widest range of venting and termination options available.
High Water Content
- Provides stable temperature control
- Low sensitivity to water flow changes
- Reduces short cycling
- Adapts to large or small heating loads
Reliable Low Maintenance Design
- High-performance burner design
- ASME Stamped
- Low NOx
- 2012 SCAQMD Certified
- 12-year history of reliable performance
Venting
- 2″, 3″, & 4″ diameters depending on model
- PVC, CPVC, SS & Polypropylene materials
- Flexible Polypropylene for chimney chases
- Concentric (299/399 only) or twin pipe
- Extended vent lengths up to 100 feet
- Common vent for multiple boilers (299/399 only)
Terminations
- Traditional PVC/CPVC/PP/SS piping elbows
- Flush-mount PVC for twin pipes
- Flush-mount Stainless Steel for twin pipes
- Single hole Concentric Termination for twin pipes
- Horizontal Concentric Termination (299/399 only)
- Horizontal and Vertical Common Vent Terminations (299/399 only)
